Description
4-pole loudspeaker connection with a robust metal housing male. Max. Current of 40 amps
Standard black strain relief: suitable for Ø8.5~11.5 mm cable sheath diameter
White strain relief: suitable for Ø11.5~13 mm cable sheath diameter
Length: 79.5 mm
Width: 26 mm
Height: 26 mm
| Series: | SP-Serie |
| Version (Plug / Chassis): | Cable Version |
| Connector type: | Speaker Connector 4 pol |
| Number of contacts: | 4 |
| Gender (M / F): | Male plug |
| Cable diameter min. in mm: | Ø 8.5 mm |
| Cable diameter max. in mm: | Ø 14 mm |
| Cable connection size max. in mm: | Ø 4 mm |
| Cable connection size max. in AWG: | AWG 11 |
| Wiring mode: | Solder contact |
| Material connector housing: | ZZnAI4-0 (Nickel) |
| Material contact: | Zink (Silber beschichtet) |
| ROHS according to EN62321-1: | Ja |
| Country of origin: | China |
| Operating voltage (VAC.RMS): | 250 V |
| max. Rated current (A): | 40 A |
| Applications: | video technician, Maschinenbauer*in, DJ, Lighting technician, Sound engineer |
